OE-MH Gen 3 Hardware Manual - Features and Contents
Power, Status and Network Lights
Default Administrator Username and Password
Important Safeguards
View Important Safeguards before installing the recorder.
Warranty
View the Product Warranty for the recorder.
Product Description
The OpenEye MH-Series recorder is designed to offer maximum performance and reliability, paired with full integration with OpenEye Web Services (OWS). Complete network setup is fast and easy using Web Connect and eliminates the need for port forwarding using OWS. There is no need to write, remember, or type IP addresses and other network information for remote connections. Simply enable OWS on your recorder, and then connect using the OWS Web Client to manage recorder configurations and user access. These recorders have RAID storage and redundant OS drive options to ensure you get as much operational up-time possible. With on-board storage and removable front drive bays, you have convenient and expandable storage capabilities.
OpenEye Web Services allows you to centralize user management, monitor the health of your recording system, and take advantage of the security of online export and video or clip file sharing.
To learn more about the MH-Series recorder or the rest of OpenEye’s M-Series recorder lineup visit openeye.net.
Controls and Connections
MH Gen 3 Front Panel
MH Gen 3 Rear Panel
Power, Status and Network Lights
The LED lights can be found on the front panel between the USB ports and Power Switch.
- USB 3.0 Ports
- System Reset Button
- Alarm Mute Button
- System HDD Activity LED
- Power LED
- Failure LED
- LAN1 & LAN2 LED
- Power Switch
When properly connected to a power source, the LED lights indicate the state of the appliance.
| LED | Color | Status |
| Power | Blue | Power On |
| HDD | Yellow | HDD is busy |
| Error | Red | Signal is in error |
| LAN1 - LAN2 | Green | Internet is busy |
Features
Box Contents
OpenEye MH-Series recorders come with a power cord, mouse, and a rack mount installation kit. Identify the following components to make sure everything has been properly included with your new recorder. If any of the following items are missing, contact the dealer to arrange a replacement.
|
OE-MH Recorder |
Locking Front Bezel |
|
Mouse |
Power Cord |
|
Mounting Hardware |
|
