Important Safeguards

View Important Safeguards before installing the camera.

Warranty

View the Product Warranty for the camera.

Product Description

The OE-C3012T4B-S is a black 4MP outdoor IP turret camera equipped with a 2.7~13.5mm varifocal, autofocus, zoom lens and person, vehicle, and line crossing detection analytics. True WDR and true day/night functionality allow the camera to adapt to changing lighting conditions throughout the day to ensure high-quality images. Adaptive IR technology prevents overexposure of objects close to the camera further enhancing the low-light performance.

Painted black, the OE-C3012T4B-S can be concealed in various low-light installation environments, adding further obscurity. The IK10 and IP67-rated housing make it well-suited for installation in any area without concern for inclement weather or vandalism.

The OE-C3012T4B-S is compatible with all 30-Series mounting accessories to fit a broad range of applications making it an excellent choice for users looking for a cost-competitive, full-featured smart camera.

Combine the analytics capabilities of this camera with OpenEye Web Services to receive real-time alerts, on person, vehicle or line crossing detection, sent directly to your mobile device or PC.

Camera Dimensions

OE-C3012T8-S Front Line Drawing.png

OE-C3012T8-S Side Line Drawing.png

OE-C3012T8-S Line Drawing Bottom.png

Connections

OE-C3012T4-S Line Connections.png

1 RJ45 For connector and PoE connections
2 Power (12vDC) Power connection
Power Connection

For an adequate power connection, use a 12vDC adaptor. Alternatively, you can power the camera by PoE if a Power Sourcing Equipment (PSE) switch is available. Ensure that the camera’s power cable is correctly and firmly connected.

NOTE: OpenEye recommends against using more than one power source at a time. Do not use a PoE power source when providing the camera with 12vDC power.

If using Power over Ethernet (PoE), make sure Power Sourcing Equipment (PSE) is in use in the network.

Features
  • Person, Vehicle, Line Crossing Analytics
  • Black Housing
  • Low Maintenance
  • NDAA Compliant
  • Corridor Mode
  • True WDR @ 4MP
  • Adaptive IR – up to 131’
  • 2.7~13.5mm VF, AF, Zoom Lens
  • 4MP Resolution | Up to 30FPS
  • IK10 Impact Protection Rating
  • IP67 Ingress Protection Rating
  • Smart Compression
  • Built-in microphone
Box Contents

OpenEye C3012T4B-S cameras come with self-tapping screws and plastic anchors mounting template, and waterproof cable connector. Identify the following components to make sure everything has been properly included with your new recorder. If any of the following items are missing, contact the dealer to arrange a replacement.

OE-C3012T8-S Front Line No Callouts.png

OE-C3012T4B-S Turret Camera

Screws and Anchors.png

Self-Tapping Screws and Plastic Anchors x3

OE-C3012T8-S mounting template.png

Mounting Template



waterproof cable connector.png



Waterproof Cable Connector
