OE-C2012B4-S Hardware Manual - Features and Contents

  1. Last updated
  2. Save as PDF
Important Safeguards

View Important Safeguards before installing the camera.

Warranty

View the Product Warranty for the camera.

Camera Dimensions

C2012B8-S Line Dimensions.png

Connections

C2012B8-S Connections Callouts.png

1 RJ45 For network and PoE connections
2 Power (12vDC) Power Connection (12vDC power input should be plugged when not in use)
3 Audio I/O Ground
Audio In
Audio Out
4 Alarm I/O Ground
Alarm In
Alarm Out -
Alarm Out +
Power Connection

For an adequate power connection, use a 12vDC adaptor. Alternatively, you can power the camera by PoE if a Power Sourcing Equipment (PSE) switch is available. Ensure that the camera’s power cable is correctly and firmly connected.

NOTE: OpenEye recommends against using more than one power source at a time. Do not use a PoE power source when providing the camera with 12vDC power.

If using Power over Ethernet (PoE), make sure Power Sourcing Equipment (PSE) is in use in the network.

Resetting the Camera

C2012B8-S Reset and SD Card.png

1 Reset

To restore the camera to factory defaults:

  1. Disconnect power for 30 seconds.
  2. Reconnect power and wait 30 seconds.
  3. Close the jumper connection with a proper tool for 20 seconds.
2 MicroSD Card Slot

Supports up to 512GB microSD card for Edge storage.

Do not add or remove the microSD card when the camera is powered on.
Features
  • Person, Vehicle, Line Crossing Detection Analytics
  • 2.7~13.5mm VF, AF, Zoom Lens
  • 4MP | Up to 30FPS
  • Excellent Low Light Performance
  • NDAA Compliant
  • Adaptive IR | Up to 164'
  • True WDR @8MP
  • Audio I/O
  • Alarm I/O
  • IK10 Impact Protection Rating
  • IP67 Ingress Protection Rating
  • Corridor Mode
  • Large size creates a strong visual deterrent
Box Contents

OpenEye C2012B4-S cameras come with self-tapping screws and plastic anchors, mounting template, and a waterproof cable connector. Identify the following components to make sure everything has been properly included with your new recorder. If any of the following items are missing, contact the dealer to arrange a replacement.

C2012B8-S Line Drawing no Callouts.png

OE-C2012B4-S Bullet Camera

Screws and Anchors.png

Self-Tapping Screws and Plastic Anchors x3

C2012B8-S Mounting Template.png



Mounting Template



waterproof cable connector.png



Waterproof Cable Connector
